A Range of steam generators available for all types of Steam Rooms.

Units are locally manufactured and designed to be as robust as possible, using only locally made components which means spares will always be available.

Steam Generators are supplied DIY & Installed & include the following:

• 12 Month Warrantee
• Installation & Operating Instructions
• Steam Nozzles, Sensor Holder & Temperature Sensor

Steam Generators are rated according to the size of the room (cubic meters) and power supply available, e.g. Single or Three Phase.

Steam Generators require the following:

• 15mm Cold Water Supply.
• Power Supply.
• Installed in a dry, ventilated area, outside the steam room.
• Provision to drain the machine for maintenance purposes.
• 22mm Copper pipe to deliver steam to the steam room.

Maintenance required:

• Units are to be drained on a regular basis to prevent a build up of sediment inside the tank and to prolong the life of the elements. After use for Domestic installations and daily for Commercial installations.

4kW Steam Generator

Single phase power unit.

Rated for steam room not exceeding 2.5 cubic meters.

1 Steam outlet.

Steam Generators for Steam Rooms, Steam Showers, Rasul & Hammam…

6kW Steam Generator

Single or Three phase power unit.

Rated for steam room not exceeding 4 cubic meters.

1 Steam outlet.

7kW Steam Generator

Single or Three phase power unit.

Rated for steam room not exceeding 4.5 cubic meters.

1 Steam outlet.

Single or Three Phase Power Units.

9kW Steam Generator

Three phase power unit.

Rated for steam room not exceeding 6 cubic meters.

2 Steam outlet.

12kW Steam Generator

Three phase power unit.

Rated for steam room not exceeding 8 cubic meters.

2 Steam outlet.

15kW Steam Generator

Three phase power unit.

Rated for steam room not exceeding 10 cubic meters.

2 Steam outlet.

Three Phase Power Units.

18kW Steam Generator

Three phase power unit.

Rated for steam room not exceeding 12 cubic meters.

2 Steam outlet.

24kW Steam Generator

Three phase power unit.

Rated for steam room not exceeding 16 cubic meters.

2 Steam outlet.

Repairs & Maintenance to all locally manufactured and imported Steam Generators.
